Dimensions (w x h x d):
93 x 42 x 20 mm
Protection class:
IP52
Weight:
40 g
Mounting:
In Kamstrup 162/382/351
Supply voltage:
Internal power supply
Electrical characteristics
Frequency:
50/60 Hz
Power consumption (max):
<2.5 W
Power consumption (nom):
<1 W
Installation category:
CAT 4
Environmental specifications
Operating temperature:
-20 °C to +55 °C
Operating humidity:
5 % to 90 %, non-condensing
Operating altitude:
0-2000 m
Usage environment:
Indoors
Storage temperature:
-40 °C to +85 °C
Temperature sensor, margin of error
Humidity sensor, margin of error
Green LED:
Power
Red LED:
Error
Yellow LED:
GSM status
Push button:
Factory reset
Configuration:
SMS, HTTP, GSM CSD, Telnet
Real-time clock backup:
12 h
Real-time clock accuracy:
<2 s/day
Script engine:
Intelligent script engine for active content generation
Software/firmware update:
GSM/GPRS/HTTP
Metering reports:
HTTP, FTP, SMTP (e-mail)
GPRS class:
Up to 8
Band:
850/900/1800/1900 MHz
Meter implementation:
Kamstrup 162/382/351
EMC:
EN 61000-6-2, EN 61000-6-3
Safety:
EN 61010-1, CAT 4
Connections and Interfaces
Protection class:
IP52
Dimensions (w x h x d):
93 x 42 x 20 mm
Weight:
40 g
Mounting:
In Kamstrup 162/382/351
Antenna:
Built-in, or optionally external via SMA female
SIM card:
Slide, standard size
Supply voltage:
Internal power supply
Frequency:
50/60 Hz
Power consumption (max):
<2.5 W
Power consumption (nom):
<1 W
Installation category:
CAT 4
Operating temperature:
-20 °C to +55 °C
Operating humidity:
5 % to 90 %, non-condensing
Operating altitude:
0-2000 m
Usage environment:
Indoors
Storage temperature:
-40 °C to +85 °C
Green LED:
Power
Red LED:
Error
Yellow LED:
GSM status
Push button:
Factory reset
Configuration:
SMS, HTTP, GSM CSD, Telnet
M-Bus standard:
EN 13757
Real-time clock backup:
12 h
Real-time clock accuracy:
<2 s/day
Script engine:
Intelligent script engine for active content generation
Software/firmware update:
GSM/GPRS/HTTP
Metering reports:
HTTP, FTP, SMTP (e-mail)
GPRS class:
Up to 8
Band:
850/900/1800/1900 MHz
Meter implementation:
Kamstrup 162/382/351
EMC:
EN 61000-6-2, EN 61000-6-3
Safety:
EN 61010-1, CAT 4
1 meter:
500 days
Communication:
GPRS
CMi2140 Data Sheet English
